Arturo EP2490

Electrical conducting self-smoothing floor for ESD protection areas and cleanrooms (2-C,  EP)

Applications

It is suitable on ESD-protection-zones, where a small electrostatic charge and a conductive surface are required. Arturo EP2490 is especially suitable as a finish on floors that are exposed to light and medium loads on mineral subsoils, for example for:

  • Rooms with sensible electronics
  • Semiconductors and electronics industry
  • Microbiology and chemistry
  • Pharmacy
  • Production rooms for electric parts

Properties

  • Electrically conducting
  • Component protection
  • Correspond ESD requirements according to DIN EN 61340-5-1
  • Resistant to impacts, shocks and wear
  • Impermeable to liquids
  • Available in lots of colours
  • Easy handling
  • Self-smoothing

Technical data

Consumption

Approx. 1.50 kg/m²/mm. Max. 3.75 kg/m²

Mixing ratio

85.0 part by weight comp. A
15.0 part by weight comp. B

Full mechanical resilience

After 3 days*

Water and chemically resistant

After 7 days*

Layer thickness

Approx. 2.00 mm (max. 2,5 mm)

Solids content

100%

Shore-D (7d/21°C/60% r.h.)

Approx. 80

Tensile strength (7d/21°C/60% r.h.)

19 MPa (N/mm²)

Compressive strength (7d/21°C/60% r.h.)

58 MPa (N/mm²)

Ordering information

Article Article number Packsize
Arturo EP2490 10 kg Multiple colours Set: A + B = 10 kg: A = 8.50 kg, B = 1.50 kg
Arturo EP2490 25 kg Multiple colours Set: A + B = 25 kg: A = 21.25 kg, B = 3.75 kg
Arturo EP2490 A 21,25kg Multiple colours Set: A + B = 25 kg: A = 21.25 kg, B = 3.75 kg
Arturo EP2490 A 8,50kg Multiple colours Set: A + B = 10 kg: A = 8.50 kg, B = 1.50 kg
Arturo EP2490/EP2500 B 1,50kg 74100 Set: A + B = 10 kg: A = 8.50 kg, B = 1.50 kg
Arturo EP2490/EP2500 B 3,75kg 74093 Set: A + B = 25 kg: A = 21.25 kg, B = 3.75 kg

Quality seals and badges

Arturo_Pictogram_Scratch_EN
Arturo_Pictogram_Impermeable_EN
Arturo_Pictogram_Maintenance_EN
Arturo_Pictogram_Seams_EN
Arturo_Pictogram_Fire_EN
Arturo_Pictogram_Electrically_EN
